Bandsaw / resaw

CENTAURO R800

Technische Daten:
fly wheel DM 800 mm
Max. cutting height 400 mm
Max. max cutting width 780 mm
tabel dimensions 580 x 810 mm
tildable table 15 Grad
Max. saw blade dimension 80 x 0,8 mm
saw blade length 5380 - 5530 mm
motor 11,0 kW, 400 V, 50 Hz
suction 2 x 100 mm
fly wheel speed 680 U/ min
suction DM 1 x DM 100 mm & 2 x DM 120 mm
compressed air 6 - 8 bar

machine weight: ca. 850 kg
machine dimensions L x B X H 1550 x 950 x 2500 mm

welded steel structure, fully closed
pneumatic brake
table in cast iron
Psdpfjby U Dpsx Appjgu
upper & lower saw blade guide
star triangle switch
emergency push button
telescopic saw blade guard/ guide
work table tillable 20 deg.
saw blade cooling/ cleaning device with diesel tank
saw blade tension indicator
cleaning brush for fly wheels
solid work piece fence
cast iron fly wheels
motor circuit protection switch
CE


CENTAURO
Model RVP200

feeder roller height 160 mm
work piece fence with rollers height 160 mm
var. feed speed 1 - 21 m/ min
pneumatic opening / closing of feeder
Max distance saw blade - feeder approx 220 mm
Max. distance saw blade - work piece fenceapprox . 200 mm
CE
