লেদ - চক্র নিয়ন্ত্রিত

VDF Boehringer VDF630 DUS

Model: VDF Boehringer DUS 630

Swing diameter over bed: 640 mm

Swing diameter over cross slide: 435 mm

Travel of cross slide / top slide: 365 mm / 145 mm

Center height over flat bed: 320 mm

Distance between centers: 1,500 mm

Cross slide dimensions (W x L): 265 x 630 mm

Top slide dimensions (W x L): 220 x 425 mm

Turning tool section: 32 x 25 mm

Spindle bore: 70 mm

Front spindle diameter: 100 mm

Max. torque (40% / 100% duty cycle): 1,600 / 640 Nm

Speed range (overall): 3–2,500 rpm

Gear stages: 2

Constant cutting speed: 1–9,999 m/min

Feed range transverse/longitudinal: 0.01–50 mm/rev
Guedpfx Aajwywxdj Isb

Max. feed rate transverse/longitudinal: 10 m/min

Rapid traverse transverse/longitudinal: 5 m/min

Feed force transverse/longitudinal: 12,500 N

Metric thread pitches: 0.1–400 mm

Quill diameter / stroke / taper: 100 mm / 190 mm / MT5

Faceplate: Ø 630 mm

Setover tailstock center: Ø 150 mm

Workpiece weight (max.):

Between centers: 400 kg

With tailstock & 2 steadies: 1,600 kg

Display: 10.4" color LCD, showing (among others) spindle speed, feed rate, position, tool, load
