TECNOVA ES130N 37D ডিগ্রী

TECNOVA ES130N 37D DEG

Single-screw extruder manufactured in 2005. This TECNOVA ES130/37D DEG features a screw diameter of Ø 130 mm and an L/D ratio of 37:1. It includes a powerful main motor rated at 246 HP and a degassing system for enhanced processing. The barrel temperature control offers individually controlled heating and cooling zones, ensuring optimal performance. If you are looking to get high-quality plastic processing capabilities, consider the TECNOVA ES130/37D DEG machine we have for sale. Contact us for further details.

• L/D ratio: 37:1*
• Main motor power: 246 HP (approx. 181 kW)
• Degassing system: Yes
• Barrel temperature control: Individually controlled heating and cooling zones
• Barrel cooling: Forced-air cooling with fans
• Barrel heating capacity: approx. 110.6 kW total
• Electrical supply: 380 V / 50 Hz / 3-phase
• Main electrical rating: 630 A
• Control voltage: 110 V
• Electrical cabinet protection: IP44
• Extruder length: approx. 4,635 mm

Additional equipment
Bdodpfx Acez Az Ace Asi

• Vacuum pump (included)
