SCHRÖDER-FASTI PowerShear 3000x6mm

Hydraulic plate shear
Manufacturer: Schrödergroup, Type: Powershear – 3000 x 6mm
Year of manufacture: 2020
Credpfezi Ezvsx Anpod

Technical data

Manufacturer: Schröder
Type: 530 - 30/6
Year of manufacture: 2020
Sheet width: 3040 mm
Sheet thickness: 6.00 mm (400N/mm)
Shear gap adjustment: 0.5 – 1.8 mm
Stroke rate: 24-61 strokes/min
Drive power: 12.0 kW
Space requirement (L x W x H): approx. L 4.00 x 3.00 x 1.96 m
Weight: approx. 6.5 t

Equipment

- 12" touchscreen control PSC 150 on a swiveling panel
- energy-efficient drive for frequency-controlled motor and pump
- automatic shear gap adjustment
- Adjustable clamping pressure, pre-selectable via the control unit
- motorized back gauge 10-1000 mm on ball screw spindles
- pneumatic sheet metal holding device
- LED cutting edge lighting
- programmable start and end position of the blade beam
- angle stop mounted on the left, incl. electronic length measuring system, fine adjustment and
side folding stop on linear guide 1000 mm
- 2 stop arms with ball rollers, movable on a linear guide
- table support made of stainless steel sheets, incl. ball rollers
- protection of the rear side with a light curtain
- scrap and small parts chute to the front, incl. "Return to Sender" function
- movable table extension mounted on a guide rail
- finger guard, retractable to approx. 1500 mm, incl. electrical protection

All information without guarantee.
A demonstration is possible at any time in our showroom.
