SCHÜCO PDG E CUT

SCHÜCO PDG E CUT

This 3-axis SCHÜCO PDG E CUT was manufactured in 2009. It features a maximum saw blade diameter of 600 mm and operates at a motor speed of 2410 min⁻¹. The machine includes a discharge conveyor belt and an extraction system for efficient operation. If you are looking to get high-quality cutting capabilities, consider the SCHÜCO PDG E CUT double mitre saw we have for sale. Contact us for further details.

• Motor speed: 2410 min⁻¹
• Max saw blade diameter: 600 mm
• Motor type: M 100, 4 kW
• Electrical connection: 3~ 400 V / 50 Hz / 7.7 A
• machinable material: Aluminium
• Height [mm]: 1870
• Depth [mm]: 2100
• Compressed air: 7 bar
• Coverage: 53
• Consumption unit: NL/cycle
• Locating hole: 32 mm
• Control voltage type: DC
• Width [mm]: 7125
• Supply voltage (machine): 400 V
• Voltage type (machine): AC
• Frequency (machine): 50
• Motor output: 2 x 2.2 kW
• Control voltage: 24 V
• Max. Cutting length: 5000 mm
• Min. cutting length: 350 mm
• Min. cutting length with software: 270 mm
Njdpfoyv E Edsx Ak Tslf
• Execution: 5 m
• Angle setting: Via servo motors
• Tilt angle (outside): up to 20°
• Tilt angle (inside): up to 45°

Additional equipment

• Discharge conveyor belt (Abtransportband)
• Extraction system (Absauganlage), brand: Emmegi
