HOLZMA Maschinenbau GmbH HPL510/43/22/L/D/X

For sale is a professional, industrial panel dividing saw from the premium manufacturer HOLZMA, from the high-performance 510 series. The system is of German manufacture ("Made in Germany") and is specifically designed for tear-free and dimensionally accurate cutting of large quantities of panels in an industrial multi-shift operation.

As an HPL version, this system features fully automatic material feeding from the rear via a heavy-duty lifting platform, which minimizes cycle times and maximizes operator ergonomics.

Technical data according to specification (HPL 510/43/22/L/D/X)

Manufacturer: HOLZMA Maschinenbau GmbH
Exact model designation: HPL 510 / 43 / 22 / L / D / X
Cutting length (code 43): max. 4,300 mm
Dsdpfx Aijzilz Nj Rjcn
Table width (code 22): max. 2,200 mm
Saw blade overhang: 125 mm
Main saw blade diameter: max. 450 mm
Working height (table height): approx. 1,020 mm (adjustable via leveling feet)
Overall height: approx. 2,100 – 2,200 mm (depending on terminal configuration)

Control & Clamping System

Machine control: Equipped with the proven, IPC-based high-performance control system HOLZMA CADmatic 4. This offers intuitive operation via graphic displays, plain-text error diagnoses, and an optimized cutting sequence visualization.

Material clamps: The program slider is equipped as standard with 9 robust, two-finger HOLZMA clamps for gentle and highly precise package fixing.

Electrical connection values & energy

Operating voltage: 400 V (three-phase / three-phase AC)
Mains type: 3~ + N
Frequency: 50 Hz
Rated current: 52 A
Required fuse rating: 63 A, slow-blow
Control voltage: 24 V

Equipment and functional features

Automatic cutting height control: The saw carriage automatically adjusts the overhang of the main saw motor (13.5 kW) and the scoring unit (2.2 kW) to the measured package height.

Intelligent pressure beam (pneumatic): Variable opening height for a significant reduction in idle times between cuts.

Heavy-duty lifting table feeding ("L"): Robust 4-column feeding system at the rear, designed for smooth handling of heavy panel stacks.

Equipment packages ("D" & "X"): Extended machine equipment for optimized material flow, precise package stop, and high-performance cutting cycles.

Important logistics and sales information

Condition & Packaging: The machine has already been professionally dismantled and is completely packed, ready for loading. The professional transport securing of all sensitive axes, linear guides, and control components has been carried out in accordance with the manufacturer's specifications.

Cost assumption: The loading and transport costs are not included in the purchase price and must be borne entirely by the buyer. Recommendations for local crane and transport services can be requested from us. We will assist with the collection as much as possible.
